DS33R11 Ethernet Mapper with Integrated T1/E1/J1 Transceiver
199 of 344
Register Name:
SU.TxFrmUndr
Register Description: MAC Transmit Frame Under Run Counter
Register Address: 0334h (indirect)
0334h:
Bit
# 31 30 29 28 27 26 25 24
Name TXFRMU31 TXFRMU30 TXFRMU29 TXFRMU28 TXFRMU27 TXFRMU26 TXFRMU25 TXFRMU24
Default 0 0 0 0 0 0 0 0
0335h:
Bit
# 23 22 21 20 19 18 17 16
Name TXFRMU23 TXFRMU22 TXFRMU21 TXFRMU20 TXFRMU19 TXFRMU18 TXFRMU17 TXFRMU16
Default 0 0 0 0 0 0 0 0
0336h:
Bit
# 15 14 13 12 11 10 09 08
Name TXFRMU15 TXFRMU14 TXFRMU13 TXFRMU12 TXFRMU11 TXFRMU10 TXFRMU9 TXFRMU8
Default 0 0 0 0 0 0 0 0
0337h:
Bit
# 07 06 05 04 03 02 01 00
Name TXFRMU7 TXFRMU6 TXFRMU5 TXFRMU4 TXFRMU3 TXFRMU2 TXFRMU1 TXFRMU0
Default 0 0 0 0 0 0 0 0
Bits 0 - 31: Frames Aborted Due to FIFO Under Run Counter (TXFRMU[0:31]) 32 bit value indicating the
number of frames aborted due to FIFO under run. Each time a frame is aborted due to FIFO under run, this
counter is incremented by 1. This counter resets only upon device reset, does not saturate, and rolls-over to zero
upon reaching the maximum value. The user should ensure that the measurement period is less than the minimum
length of time required for the counter to increment 2^32-1 times at the maximum frame rate. The user should store
the value from the beginning of the measurement period for later calculations, and take into account the possibility
of a roll-over to occurring.
