57
Owner’s Manual
Table 3-4 Result Codes
Terse Verbose Description
0 OK Command executed
1 CONNECT Modem connected to line
2 RING Ring signal detected
3 NO CARRIER Carrier signal lost or not detected
4 ERROR Invalid command
5 * CONNECT 1200 Connected at 1200 bps
6 NO DIALTONE No dial tone detected
7 BUSY Busy signal detected
8 NO ANSWER No answer at remote end
10 * CONNECT 2400 Connected at 2400 bps
11 * CONNECT 4800 Connected at 4800 bps
12 * CONNECT 9600 Connected at 9600 bps
13 * CONNECT 7200 Connected at 7200 bps
14 * CONNECT 12000 Connected at 12000 bps
15 * CONNECT 14400 Connected at 14400 bps
16 * CONNECT 19200 Connected at 19200 bps
17 * CONNECT 38400 Connected at 38400 bps
18 * CONNECT 57600 Connected at 57600 bps
19 * CONNECT 115200 Connected at115200 bps
22 * CONNECT 75TX/1200RX Connected at V.23 Originate
23 * CONNECT 1200TX/75RX Connected at V.23 Answer
24 * DELAYED Delay is in effect for the dialed number
32 * BLACKLISTED Dialed number is blacklisted
33 FAX Connected FAX mode
35 DATA Connected DATA mode
40 * CARRIER 300 0-300 bps Data Carrier Detected
44 * CARRIER 1200/75 V.23 Backward Channel Detected
45 * CARRIER 75/1200 V.23 Forward Channel Detected
46 * CARRIER 1200 1200 bps Data Carrier Detected
47 * CARRIER 2400 2400 bps Data Carrier Detected
48 * CARRIER 4800 4800 bps Data Carrier Detected
49 * CARRIER 7200 7200 bps Data Carrier Detected
50 * CARRIER 9600 9600 bps Data Carrier Detected
51 * CARRIER 12000 12000 bps Data Carrier Detected
52 * CARRIER 14400 14400 bps Data Carrier Detected
53 * CARRIER 16800 16800 bps Data Carrier Detected
54 * CARRIER 19200 19200 bps Data Carrier Detected
55 * CARRIER 21600 21600 bps Data Carrier Detected
