44
Model MT5600ZDX
S-Registers
Certain Command Mode configurations are stored in memory registers
called, S-Registers. The S command is used to assign a value to, and to
read the current value of an S-Register. To assign a value to an S-Register,
enter the letter S, followed by the S-Register number and an equals sign
(=). To read an S-Register value, enter the letter S followed by the S-
Register number and a question mark (?), then hit RETURN. To verify that
the S-Register value was entered correctly, enter for example, ATS8? and
hit RETURN. You should receive a response of the assigned value given to
that S-Register.
Register Unit Range Default Description
S0 rings 0, 1–255 1 Sets the number of rings before
the modem answers. ATS0=0
disables auto-answer complete-
ly.
S1 rings 0–255 0 Counts the number of rings that
have occurred.
S2 decimal 0–255 43 (+) Sets ASCII code for the escape
character. Values greater than
127 disable the escape sequence.
S3 decimal 0–127 13 (^M) Sets ASCII code for the carriage
return character.
S4 decimal 0–127 10 (^J) Sets ASCII code for the line feed
character.
S5 decimal 0–255 8 (^H) Sets ASCII code for the backspace
character. Values greater than 32
disable the backspace character.
S6 seconds 2–255 2 Sets the time the modem waits
after it goes off-hook before it
begins to dial the telephone num-
ber.
S7 seconds 1–255 50 Sets the time the modem waits
for a carrier signal before abort-
ing a call. Also sets the wait for
silence time for the @ dial modi-
fier.
