Register Unit Range Default Description
S27 Bit Mapped Options Status (Indicates the status of command
Options.) Default: 73 (49h)
Bit 0, 1, 3 Sync/Async
3 1 0
0 0 0 = &M or &Q0
0 0 1 = &M1 or &Q1
0 1 0 = &M2 or &Q2
0 1 1 = &M3 or &Q3
1 0 0 = &Q4
1 0 1 = &Q5 (Default)
1 1 0 = &Q6
Bit 2 Leased Line Control
0 = Dial Up Line (&L0)--Default
Bit 4-5 Internal Select Clock
0 = Internal Clock (&X0)--Default
1 = External Clock (&X1)
2 = Slave Clock (&X2)
Bit 6 CCITT/Bell Mode Select (Bn)
0 = CCITT (B0)
1 = Bell Mode (B1)--Default
Bit 7 Reserved
S28 Bit-Mapped Options Status Default: 0
Bit 0-1 Reserved
Bit 2 Reserved (always 0)
Bit 3-4 Pulse Dialing (&Pn)
0 = 39%-61% make/break ratio at 10 pulses per second (&P0)--
Default.
0 = 33%-67% make/break ratio at 10 pulses per second (&P1).
0 = 39%-61% make/break ratio at 20 pulses per second (&P2).
0 = 33%-67% make/break ratio at 20 pulses per second (&P3).
