50
Model MT5600ZDX
S29 1 minute 0–255 70ms Sets the length of time, in units of
10 ms, that the modem will go
on-hook when it encounters a
flash (!) dial modifier in the dial
string. The time can be limited as
it is a country dependent param-
eter.
Register Unit Range Default Description
S30 1 minute 0–255 0 S30 specifies the length of time
(in tens of seconds) that the
modem waits before discon-
necting when no data is sent or
received. This function is only
applicable to buffermode.
S31 Bit-Mapped Options Status (Indicates the status of command
Options.) Default: 194
Bit 0 Single Line Connect Message Enable/Disable (\Vn)
0 =Messages controlled by S95, Wn and Vn (\V0)-
-Default
1 =Single Line Connect Message (\V1)
Bit 1 Auto Line Speed Detection (Nn)
0 = Disabled (N0)
0 = Enabled (N1)--Default
Bit 2-3 Error Correction Progress Messages (Wn)
0 = DTE speed only (W0)--Default
1 = Full Reporting (W1)
2 = DCE speed only (W2)
Bit 4-5 Caller ID (#CID)
0 = Caller ID Disabled (#CID = 0)--Default
1 = Short Formatted Caller ID Enabled (#CID = 1)
2 = Long unformatted Caller ID Enabled (#CID = 2)
Bit 6-7 Reserved
S32 decimal 0–255 17 Sets the value of the XON charac-
ter.
S33 decimal 0–255 19 Sets the value of the XOFF charac-
ter.
