45
Owner’s Manual
Register Unit Range Default Description
S8 seconds 0–255 2 Sets the length of a pause caused
by a comma character in a dialing
command.
S9 1/10 sec 0–255 6 (0.6) Sets the time, in tenths of a
second, that the carrier must be
present before the modem con-
siders it valid and turns on the
RLSD.
S10 1/10 sec 1–255 14 (1.4) Sets the time, in tenths of a
second, that a carrier signal must
be lost before the modem discon-
nects.
S11 1 ms 50–255 95 Sets spacing and duration of dial-
ing tones.
S12 1/50 sec 50–255 50 (1sec) Defines the maximum period,
in fiftieths of second, allowed
between receipt of the last char-
acter of the three escape charac-
ter sequence from the DTE (es-
cape code guard time).
S14 General Bit Mapped Options Status. Indicates the status of
command options:
Bit 0 This bit is ignored
Bit 1 Command Echo (En)
0 = Disabled (E0)
1 = Enabled (E1) Default
Bit 2 Quiet Mode (Qn)
0 = Send Result Codes (Q0) Default
1 = Do not Send Result Codes (Q1)
Bit 3 Result Codes (Vn)
0 = Numeric (V0)
1 = Verbose (V1) Default
Bit 4 Reserved
Bit 5 Tone (T) /Pulse(P)
0 = Tone (T) Default
1 = Pulse (P)
Bit 4 Reserved
Bit 7 Originate/Answer
0 = Answer
1 = Originate (Default)
