MT5634ZPX 13
2 Installation
Safety Warnings
• Never install telephone wiring during a lightning storm.
• Never install telephone jacks in wet locations unless the jack
is specifically designed for wet locations.
• This product is to used with UL and CUL listed computers.
• Never touch uninsulated telephone wires or terminals unless
the telephone line has been disconnected at the network
interface.
• Use caution when installing or modifying telephone lines.
• Avoid using a telephone (other than a cordless type) during
an electrical storm. There may be a remote risk of electrical
shock from lightning.
• Do not use a telephone in the vicinity of a gas leak.
Installation
Installation of the MultiModemZPX consists of four steps: (1)
Configuration of the modem’s DIP-Switch and Jumper settings,
(2) installation of the modem in the computer; (3) connection of
the modem to the telephone line and, optionally, to an external
speaker and microphone; and (4) installation of the modem’s
drivers.
Note: Unless otherwise noted, these procedures are for both PnP
and non-PnP environments.
Figure 2-1. MultiModemZPX
