Replacing system fans www.gateway.com
45
7 Slide the fan board away from the power supply (5), then remove it from
the chassis (6).
8 Place the new fan board on the standoffs in the chassis, then slide it toward
the power supply to lock it down.
9 Tighten the thumbscrew to secure the fan board in place.
10 Connect the cables to the fan board.
11 Place the fan cage on the fan board, then tighten the two screws
(previously loosened) to secure the fan cage in place.
12 Insert the fans into the fan cage until they click into place.
13 Follow the instructions in “Closing the server case” on page 30 .
