Gateway Server E-9520T - Manual (Page 101)

Electronic specifications www.gateway.com
95
Serial port connector (J15)
Keyboard and Mouse connectors
25 GND 26 TRK_0_N
27 MSEN 0 28 WPROTECT_N
29 GND 30 RDATA_N
31 GND 32 HDSEL_N
33 GND 34 DSKCHING_N
Pin Signal Name Description
1 DCD Data Carrier Detect1
2 RXDATA Receive Data
3 TXDATA Transmit Data
4 DTR Data Terminal Ready
5 GND Ground
6 DSR Data Set Ready
7 RTS Request To Send
8 CTS Clear To Send
9 RI Ring Indicate
Pin Signal Name
1 Keyboard (or mouse) data
2 NC
3 GND
4 +5 V
5 Keyboard (or mouse) clock
6 NC
Pin Signal Name Pin Signal Name
