APPENDIX A: Server Specifications www.gateway.com
96
External USB connectors
I
2
C (SMBus) connector
Additional specifications
For more information about your server, such as memory size, hard drive size,
and processor type, visit Gateway’s eSupport page at
support.gateway.com . The
eSupport page also has links to additional Gateway documentation and detailed
specifications for your own server.
Pin Signal Name
1 +5 V
2 USBN Data-
3 USBN Data+
4 GND
Pin Signal Name
1 I
2
C SCL
2 I
2
C SDA
3 I
2
C Alert
4 Ground
5 +3.3 V
