CHAPTER 4: Installing Components www.gateway.com
34
Important
The hard drive carriers shown in these
illustrations may look different than the
actual hard drive carriers in your server.
2 If you are replacing a hard drive, remove the four screws that secure the
old hard drive to the drive tray, then remove the drive from the tray.
- OR -
If you are adding a hard drive, remove the four screws that secure the
dummy hard drive to the drive tray, then remove the dummy hard drive
from the tray.
3 Using the four screws you removed, install the new hard drive into the
drive tray.
Screw
Screw
Screw
Screw
