G0605x1/g0696x wiring 220v, 1-ph, 220v motor, L6-30 plug (as recommended) – Grizzly G0696X User Manual
Page 82: 220 vac, Power junction box
g0605X1-6X1, g0696X-97X (mfg. 8/11+)
-79-
READ ELECTRICAL SAFETY
ON PAGE 77!
220V Motor
OFF
Magnetic Switch
Assembly MPE-30
Angle Sensor
Digital Readout
On/Off Switch
ON
AC2
R18
14
24
23
13
AC1
L6-30 Plug
(As Recommended)
Run
Capacitor
35MFD
450VAC
Start
Capacitor
250MFD
250VAC
R/1/L1
T/5/L3
NO13
S/3/L2
NC15
U/2/T1
W/6/T3
220V
V/4/T2
NC16
NO14
A
SDE
MA-30
Ground
Hot
Hot
220 VAC
G
X
Y
Ground
Power Junction Box
Installation work and
electrical
wiring
must be done by
qualified electrician
in accordance with
all applicable codes
and standards.
RESET
96
98
1/2
3/4
5/6
18
22
26
OFF
95
SDE RA-30
B
G0605X1/G0696X Wiring 220v, 1-ph
see
Figure 155, page 78
see
Figure 154,
page 78
see
Figure 157, page 78
see
Figure 157, page 78
see
Figure 158, page 78
