-78-
READ ELECTRICAL SAFETY
ON PAGE 77!
g0605X1-6X1, g0696X-97X (mfg. 8/11+)
common Electrical components
Figure 154. g0605X1/g0696X motor junction
box.
Figure 158. g0605X1/g0696X magnetic switch.
Figure 157. digital readout and angle sensor.
Figure 155. on/off switch.
Figure 156. g0606X1/g0697X motor junction
box.
