-4- g0605X1-6X1, g0696X-97X (mfg. 8/11+)
MODEL G0605X1/G0606X1/G0696X/G0697X
12" LEFT-TILTING TABLE SAWS
Model Number G0605X1 G0606X1 G0696X G0697X
Motor 5 hp, 220v, 1-ph 7 1 ⁄
2
hp, 220v/440v,
3-ph
5 hp, 220v, 1-ph 7 1 ⁄
2
hp, 220v/440v,
3-ph
Required power Supply circuit 30 Amps 30 Amps @220v
15 Amps @440v 30 Amps 30 Amps @220v
15 Amps @440v
Speed 3450 rpm 3450 rpm 3450 rpm 3450 rpm
power Requirement 220v, 1-ph, 60 hz 220v/440v, 3-ph,
60 hz
220v, 1-ph, 60 hz 220v/440v, 3-ph,
60 hz
Full Load current Rating 18 19.5/10 18 19.5/10
plug/Outlet Type (Recommended) nEmA l6-30 l15-30/hardwire nEmA l6-30 l15-30/hardwire
Table Size (full assembly) 78 3 ⁄
4
" x 30 3 ⁄
4
" 78 3 ⁄
4
" x 30 3 ⁄
4
" 30 3 ⁄
4
" x 48 3 ⁄
4
" 30 3 ⁄
4
" x 48 3 ⁄
4
"
Table height Above Floor 35 3 ⁄
4
" 35 3 ⁄
4
" 35 3 ⁄
4
" 35 3 ⁄
4
"
Overall Machine Size 91"l x 79 1 ⁄
4
"W 91"l x 79 1 ⁄
4
"W 75"l x 47"W 75"l x 47"W
Footprint Size 22 1 ⁄
2
"l x 24"W 22 1 ⁄
2
"l x 24"W 22 1 ⁄
2
"l x 24"W 22 1 ⁄
2
"l x 24"W
Weight 715 lbs. 715 lbs. 640 lbs. 640 lbs.
Fence Type t-shape t-shape t-shape t-shape
Extension & Outfeed Tables yes yes no no
Maximum Rip Right of Blade 52" 52" 36" 36"
Maximum Rip Left of Blade 18" 18" 18" 18"
Maximum Depth of cut at 90° 4" 4" 4" 4"
Maximum Depth of cut at 45° 2 3 ⁄
4
" 2 3 ⁄
4
" 2 3 ⁄
4
" 2 3 ⁄
4
"
Maximum Blade Diameter 12" 12" 12" 12"
Arbor Size 1" 1" 1" 1"
Arbor Speed 3600 rpm 3600 rpm 3600 rpm 3600 rpm
Rim Speed 11,310 Fpm 11,310 Fpm 11,310 Fpm 11,310 Fpm
Blade Tilt (Left) 0° – 45° 0° – 45° 0° – 45° 0° – 45°
Maximum Dado Width 3 ⁄
4
" 3 ⁄
4
" 3 ⁄
4
" 3 ⁄
4
"
Spreader/Riving Knife Thickness 0.09" (2.3mm) 0.09" (2.3mm) 0.09" (2.3mm) 0.09" (2.3mm)
Required Blade Body Thickness 0.074"–0.082"
(1.9–2.1mm)
0.074"–0.082"
(1.9–2.1mm)
0.074"–0.082"
(1.9–2.1mm)
0.074"–0.082"
(1.9–2.1mm)
Required Blade Kerf Thickness 0.114"– 0.122"
(2.9mm–3.1mm)
0.114"– 0.122"
(2.9mm–3.1mm)
0.114"– 0.122"
(2.9mm–3.1mm)
0.114"– 0.122"
(2.9mm–3.1mm)
Warranty 1 year 1 year 1 year 1 year
