Page 98
98
Operating Manual
TX200
S6
CSS components
8.1.2.4
Floorstand: removing the hard disk cover
For a floorstand server you make the HDD modules accessible by removing the
hard disk cover:
Figure 23: Removing the hard disk cover
Ê
Unlock the server (1).
Ê
Remove the hard disk cover (2).
The hard disk drive cover is replaced and the server locked in the reverse order.
/
