TX200 S6 Operating Manual 27
Preface
Mechanical specifications
Weight
max. 36.8 kg (depending on configuration).
Ventilation clearance
At least 200 mm on the front and rear.
Maintenance area for the floorstand model
1.2 m
2
on the left side. Emergency access must be assured.
Ambient conditions
Condensation during operation must be avoided!
Floorstand Rack
Width (with anti-tilt bracket) 205 mm (306 mm) 482 mm
Total depth 584 mm 570 mm
Installation depth ----- 596 mm
Height 444 mm 5 HU
Dimension notes Floorstand width 306 mm with tilt protection;
depth measured excludes handles on redundant
PSU. Rack depth excludes handles of
redundant PSU and rack front.
Environment class 3K2
Environment class 2K2 EN 60721 / IEC 721 Part 3-3
EN 60721 / IEC 721 Part 3-2
Temperature:
Operation (3K2) 10 °C .... 35 °C
Transport (2K2) -25 °C .... 60 °C
Humidity 10% .... 85% (non condensing)
