116 Operating Manual TX200 S6
Appendix: server specification
Onboard or integrated controllers
Serial 2 (9-pin) 1 x serial RS-232-C, optional - occupies an unused
slot
LAN / Ethernet (RJ-45) 1 x Gbit/s Ethernet
Service LAN (RJ45) 1 x dedicated service LAN connector for iRMC S2
(10/100 Mbit/s) Service LAN traffic can be switched
to shared onboard Gbit LAN port
RAID Controller Modular RAID 0/1 controller with "Integrated
Mirroring Enhanced" (SAS IME) for SAS1.0.
RAID levels 0, 1 and 1E are supported for internal
hard disk drive configurations. For the Japanese
market only RAID level 1 is supported for internal
hard disk drive configurations.
Modular RAID 0/1 controller with “MegaRAID
functionality” (SAS MegaRAID) for SAS1.0 and
SAS2.0. RAID levels 0, 1,10 and 1E are supported
for internal hard disk drive configurations.
Modular RAID 5/6 controller with "MegaRAID
functionality" (SAS MegaRAID) for SAS1.0 and
SAS2.0. RAID levels 0, 1, 10, 1E, 5, 50, 6 and 60 are
supported for internal hard disk drive configurations.
SATA Controller ICH10R, 6-port SATA (4x for internal hard disks, 2x
for accessible drives)
SATA Controller type
notes On board SATA controller supports RAID levels
0,1,10
Remote Management
Controller Integrated Remote Management Controller
(iRMC S2, 32 MB attached memory incl. graphics
controller), IPMI 2.0 compatible
Trusted Platform
Module (TPM) Infineon TCG V1.2 compliant (option)
