104 Operating Manual TX200 S6
CSS components
8.2.1 Opening the server and identifying the defective
CSS component
8.2.1.1 Opening the server
V
CAUTION!
The device can be seriously damaged if it is opened without
authorization or if repairs are attempted by untrained personnel.
It is essential to observe the safety instructions in chapter "Important
information" on page 31 .
Figure 27: Opening the server (example: floorstand model)
Ê Unlock the server.
Ê Pull the locking lever as far as it will go (1).
This pushes the side cover backward (2).
Ê Remove the side cover (3).
/
