User Manual Expert D 250 Speed / D 500 / D 1000
HENSEL-VISIT GmbH & Co. KG 83
Mount the Transport Cap
Lever for reflector holder
Fingers
 Press the locking mechanism
of the reflector holder
against the spring tension
until reaching the end stop.
 Put the transport cap onto
the unit and make sure that
the 3 fingers are inside the
wholes of the transport cap.
 Hold the transport cap with
one hand while carefully
returning the locking
mechanism of the reflector
into its standard position with
the help of the spring
tension.
 Check the secure mounting
of the transport cap.
