User Manual Expert D 250 Speed / D 500 / D 1000
Hensel-Visit GmbH & Co. KG 35
Mounting link for safety rope
 Pull the safety rope through
a suitable opening of the
pantograph.
 Fix the spring safety hook in
the mounting link for the
safety rope at the tilting
bracket.
 Insert the rope thimble in the
spring safety hook.
 Close the spring safety hook
and tighten it.
Locking screw, tilting bracket
 For tilting of the flash unit,
loosen the locking screw of
the tilting bracket.
If the tilting bracket’s locking screw cannot be opened or closed far
enough and you keep bumping against the housing, lift up (pull) the
locking screw by pressing down on the axis of the locking screw.
The locking screw’s serration loosens and you can turn the grip into a
more favorable position for further opening and closing of the locking
screw.
