User Manual Expert D 250 Speed / D 500 / D 1000
76 HENSEL-VISIT GmbH & Co. KG
Mounting a Reflector
Lever of the reflector holder
Fingers
 Press the locking mechanism
of the reflector holder
against the spring tension
until reaching the end stop.
 Put the reflector onto the unit
and make sure that the 3
fingers are inside the
reflector.
 Hold the reflector with one
hand while carefully
returning the locking
mechanism of the reflector
into its standard position with
the help of the spring
tension.
 Check the correct mounting
of the reflector.
