User Manual Expert D 250 Speed / D 500 / D 1000
Hensel-Visit GmbH & Co. KG 39
Lever of the reflector holder
Fingers
 Press the locking
mechanism of the reflector
holder against the spring
tension until reaching the
end stop.
 Put the reflector onto the
unit and make sure that the
3 fingers are inside the
reflector.
 Hold the reflector with one
hand while carefully
returning the locking
mechanism of the reflector
into its standard position
with the help of the spring
tension.
 Check the correct mounting
of the reflector.
