User Manual Expert D 250 Speed / D 500 / D 1000
64 HENSEL-VISIT GmbH & Co. KG
Remove Safety Glass Dome
The safety dome snaps into place
via three pre-installed springs
 Tilt the safety dome slightly
so that it is released one by
one from the mounting
springs.
 Pull the safety dome lightly
from the third spring and
remove it completely.
Remove Broken Flash Tube
Ignition wire
Connecting pin
 Unwind the ignition wire from
the connecting pin.
 Carefully pull the flash tube
from the plug base.
 Remove all glass debris if
necessary.
