User Manual Expert D 250 Speed / D 500 / D 1000
82 HENSEL-VISIT GmbH & Co. KG
Removing a Reflector
Lever of the reflector holder
Reflector
 Hold the reflector with one
hand.
 With the other hand, press
the locking mechanism of the
reflector holder against the
spring tension until reaching
the end stop.
Lever of the reflector holder
 Remove the reflector from the
unit and put it aside.
 Carefully return the locking
mechanism of the reflector
into its standard position with
the help of the spring
tension.
