User Manual Expert D 250 Speed / D 500 / D 1000
30 HENSEL-VISIT GmbH & Co. KG
Stand Mounting
WARNING Danger of bruising
When opening the locking screw of the tilting bracket
you are in danger of bruising your hands and fingers.
 When opening the screw of the tilting bracket,
hold the flash unit with the other hand to avert
unwanted motion.
The flash unit can be attached to a stand mounting or pantograph via the
tilting bracket. The tilting bracket allows the rotation of the flash unit of
360° and a tilting angle of approximately 180°.
Locking device, stand mounting
 Loosening the locking
device stand mounting by
turning it a few times.
 Please make sure that you
don’t turn it loose
completly.
