OPERATOR’S MANUAL
Seed Manager SE
11001-1359A-200810
STARTUP / 37
14C, 14F, and 14I. Shaft Speed Sensor Lo Limit
This constant is the lowest shaft speed (RPM) allowed before sounding a
warning alarm. The hi and lo warning limits are accessible only if the
Number of Shaft Speed Sensors has a value other than 0. The warning is
enabled or disabled by selecting the ON or OFF message. Use the
SELECT switch to advance one step to the right of the right most digit, then
press the SET switch to toggle between ON and OFF. (
Figure 38 ) shows a
limit of 12 RPM with the warning disabled.
NOTE: Use ( Figure 16 ) Setup Mode
Parameters as reference for the
following items numbered 1-21.
Figure 38
Low Limit Shaft Speed Display
15. NUMBER OF HOPPER LEVEL SENSORS
This is the actual number of hopper level sensors that are connected to all
modules in the system. This parameter will be checked as part of the
sensor/module self test and error codes will be generated if this value does
not match the actual number of hopper level sensors. (
Figure 39 ) shows a
configuration of five (5) hopper sensors.
Figure 39
Hopper Level Display
