OPERATOR’S MANUAL
Seed Manager SE
11001-1359A-200810
10 / INSTALLATION AND SETUP
Figure 7
Material Flow Module
2. Mount with the label side of the module facing out.
3. To bolt the member to a frame:
• Use the enclosure as a template to mark the location of the mounting
holes.
• Drill two 9/32 inch diameter holes where marked.
• Attach to frame using 1/4 x 20 bolts or other fastening devices as
illustrated in (
Figure 8
).
Do not use the enclosure as a guide when drilling. Do not
overtighten nuts as this may damage the mounting tabs on the
enclosure.
Preferred
Acceptable
Acceptable
