OPERATOR’S MANUAL
Seed Manager SE
11001-1359A-200810
8 / INSTALLATION AND SETUP
Figure 4
12V Battery Source Connections
Figure 5
24V Battery Source Connections
Figure 6
Negative or Positive Source Connections
IMPORTANT: Before welding on the frame or chassis, be certain to
disconnect battery leads. Failure to do so could result
in damage to the Seed Manager
®
SE.
Power
Cable
Black
Red
Black
Red
6V
6V
12V
Power
Cable
Vehicle
Ground
Vehicle
Ground
