7.7.6 Screen Scrolling and Print Functions
6-1. The Stored Data screen is capable of displaying up to (24) items with up to (500) sets
of stored data for each spindle. Due to the screen size, only (15) items and (5) cycles
of data may be displayed at once. Therefore, scrolling is necessary.
6-2. Using the
[←] [→]
keys move the cursor to [UP], [DOWN], [LEFT] or [RIGHT] and
depress the
[↵]
key to scroll.
6-3.
The [UP] [DOWN] position will scroll (15) items of the fastening data for each spindle.
The [LEFT] [RIGHT] position will scroll the stored data from 001 to 500.
6-4. To print the Fastening Data move the cursor on the menu bar to [PRINT] and depress
the
[↵]
key. The System will print the data for all the fastening cycles shown in the
screen for all the pre-selected data items, even though not all of them are shown at
the screen.
