5-1. Each limit parameter screen is capable of displaying up to 16 items. ON screens that
include more than 16 items, scrolling is necessary.
5-2. USing the
[←] [→]
keys move the cursor to [UP], [DOWN], [LEFT] or [RIGHT] and
depress the
[↵]
key to scroll.
5-3.
THe [UP] [DOWN] position will scroll all limit parameters for each spindle. THE
[LEFT] [RIGHT] position will scroll all 24 spindles.
5-4.
TO print the limit parameters, move the cursor on the menu bar to [PRINT] and
depress the
[↵]
key.
Chapter 7: System Operation
Page 7-30
