depress the
[↵]
key. Two (2) options will be given
3-4b. [SCREEN DATA CLEAR] - clears all data on the screen except for the Full
Scale Torque value and the fastening Method (Torque, Angle, etc.) [PARAMETER
NO. DATA CLEAR] - clears all data for the Parameter No. displayed on the screen,
with the exception of the Full Scale Torque value and the fastening Method (Torque,
Angle, etc). Sequence Setup should be reviewed to ensure that the cleared
Parameter No. is not in any Sequence.
3-4c. Select the desired function using the
[↑] [↓]
keys and depress the
[↵]
key.
THe question "DATA CHANGE OK?" will appear in the lower right hand corner of the
screen. SELect YES or NO using the
[←] [→]
keys and depress the
[↵]
key.
FIG. 7-1-3-4 set parameter [CLEAR] Command
3-5. SELECT Copy COMMand
3-5a. MOve the cursor on the menu bar to [COPY] using the
[←] [→]
keys and
depress the
[↵]
key.
3-5b. A pull down menu will be shown promting for the parameter number to copy
from [FROM PARAMETER NO.] and the parameter number to copy to [TO
PARAMETER NO.].
3-5c. Input the desired number in each field and select either [START] or [CANCEL].
FIG. 7-1-3-5 set parameter [COPY] Command
NOTES:
1. THe RUN/PROGRAM key switch on the MAIN UNIt must be in "PROGRAM"
mode to change data. if it is not, an error message will appear that indicates
that the machine is in "RUN MODE".
2. The nutrunner will not operate while in "PROGRAM" mode.
3. If incorrect data is entered, the System will display "INPUT ERROR".
4. A screen print can be selected from the menu bar. Use the
[←] [→]
keys
to select [PRINT] and depress the
[↵]
key.
