RS232 COMMAND TABLE (Cont.)
Command
Character
Description
CN Print Checkweighing nominal weight.
CO Print Checkweighing over limit.
CU Print Checkweighing under limit.
xCN Set Checkweighing nominal weight. Reference weight must be entered in grams.*
xCO Set Checkweighing over limit. Reference weight must be entered in grams.*
xCU Set Checkweighing under limit. Reference weight must be entered in grams. *
ID Print Current User ID String.
xID Program User ID String, 1-8 characters.
xF Sets current mode to "x"
where x = 0 to 4 (see table) 0 = "None" normal weighing mode
1 = "Percent"
2 = "Parts counting"
3 = Not used
4 = "Checkweighing"
1 = milligrams
2 = grams
3 = kilo grams
4 = dwt
5 = Carats
6 = Ounces
7 = Ounces troy
8 = Grains
9 = Taels HK (Hong Kong)
10 = Taels SG (Singapore)
11 = Taels RC (Taiwan)
12 = Mommes
13 = Pounds
14 =
15 = Newton
16 = tical
18 =
19 =
20 =
xM Places balance in unit “x”,
where x = 1 to 21 (see table).
If unit is not already
enabled, command will be ignored.
nnnn = 0 Turns feature OFF
nnnn = S Output on stability
nnnn = C Output is continuous
nnnn = 1-3600 Sets Auto Print
Interval
nnnnA Set Auto Print feature to “nnnn”
(see table).
Where:
s - sign char, '-' for neg. numbers
dddddddd - decimal digits including the decimal point
uuuuu - units indicator
? - Instability indicator
A - (A)ccept, (O)ver or (U)nder indicator for check weighing
C - Center of Zero indicator
Tare - Gross/Net/Tare indicator. "B/G" for gross, "Net" for net,
"Tare" for tare
CR
- carriage return (ASCII code 13d)
LF - linefeed (ASCII code 10d)
s d d d d d d d d u u u u u * A C T a r e CR LF
P Print display data
