10 custom unit (cont.) procedure (cont.) – Ohaus NBF1A2 Navigator Balances User Manual

Page 38

background image

38

LSD’s

LSD .5

Adds one decimal
place display counts
by 5’s.

LSD 1

Display counts by
1’s.

LSD 2

Display counts by 2’s.

LSD 5

Display counts by 5’s.

LSD 10

Display counts by 10’s.

LSD 100

Display counts by

4.10 Custom Unit (Cont.)

Procedure (Cont.)

• Press Enter button to continue, LSD is displayed.

There are 6 LSD (least significant digit) settings you
can choose from (see table below).

• Press Enter button, LSD 1 is displayed.

• Press

or

button and select LSD value either

.5, 1, 2, 5, 10 or 100.

• Press Enter button, SAVED is momentarily dis-

played followed by LOCK.

• Press Enter button.

• Press

or

button and select ON or OFF.

• Press Enter button, EXIT is displayed.

• Press Enter button to return to weighing mode.
