23
3.5 Percent Weighing
Percent Weighing is enabled only when Percent is turned ON in the Mode menu under Setup. Percent weighing
permits you to place a reference load on the balance, then view other loads as a percentage of the reference. The load
you place on the pan as a reference may be displayed as any percentage you select from 5% to 100% (in 1% incre-
ments). One hundred percent does not necessarily have to represent the reference load. Subsequent loads, displayed
as a percentage of the reference are limited only by the capacity of the balance. The default setting is Reference
100%. Refer to paragraph 4.7 to enable percent weighing.
Procedure
• Press the Mode button, WEIGH is displayed.
• Press button until PERCNT is displayed.
• Press Enter button, PUTPAN 100% is displayed. If
a container is used, the balance can be tared at this
point. The % display momentarily blanks while the
balance is taring out.
• Put the reference load on the pan.
• Press or button and select reference
weight percentage (Percent Range 5 to 100). Hold
button down for fast change.
• Press Enter button to save setting, BUSY is dis-
played while the balance calculates the reference
weight. The balance shows the 100% equivalent refer-
ence weight for two seconds in the selected measur-
ing unit, then displays the percentage which was
entered.
• To view the weight of the reference load, press the
UNITS button, then press button until unit of
measurement such as GRAMS is displayed, then
press the Enter button.
• To return to percent weighing, press the UNITS button
and then press button until PERCNT is dis-
played, then press the Enter button.
• Remove the reference weight from the pan and re-
place it with another load. The second load is dis-
played as a percentage of the reference. The display
illustrates 100% of the reference value.
• To return to weighing mode, press the MODE button
and then press button until WEIGH is displayed,
then press the Enter button.
