43
RS232 COMMAND TABLE (Cont.)
0 = minimum level
1 =
2 =
3 = maximum level
1 = milligrams
2 = grams
3 = kilo grams
4 = dwt
5 = Carats
6 = Ounces
7 = Ounces troy
8 = Grains
9 = Taels HK (Hong Kong)
10 = Taels SG (Singapore)
11 = Taels RC (Taiwan)
12 = Mommes
13 = Pounds
14 =
15 = Newton
16 = tical
17 = tola
18 =
19 =
20 =
21 = Custom Units
xF Sets current mode to "x"
where x = 0 to 4 (see table)
0 = "None" normal weighing mode
1 = "Percent"
2 = "Parts counting"
3 = "Animal weighing"
4 = "Checkweighing"
P Print display data
Field: Polarity Weight Mode Stab CR LF
Length: 1 1 7 1 5 1 1 1
When "numeric only"data is
selected for output in the
RS232 menu, the Mode field
is not output.
Same as ?
command
Displayed weight sent right justified
w/lead zero blanking.
Seven characters include:
decimal point (1)
weight (6 max)
xSL Set stability level (set x = 0 to 3). 0=.5d, 1=1d, 2=2d, 3=5d
T Same effect as pressing O/T button.
V Print software version
10 polarity (1): blank if positive
"-" if negative
Command
Character
Description
c Description
xD Set 1 second print delay (set x = 0 for OFF, or x = 1 for ON)
F Print current function.
xI Set Averaging Filter Level to “x”,
where x = 0 to 3 (see table).
L Begin linearity calibration
xM Places balance in unit “x”,
where x = 1 to 21 (see table).
If unit is not already
enabled, command will be ignored.
