Page 2-13 CHAPTER 2 — ADVANCED CONFIGURATION
!AGILE!49=00; 1 line max. vertical resolution (default)
!AGILE!49=01; 72 units max. vertical resolution
!AGILE!49=02; 127 units max. vertical resolution
!AGILE!49=03; 255 units max. vertical resolution
!AGILE!49=04; 299 units max. vertical resolution
!AGILE!49=05; No max. vertical resolution
4A-4D — Offset
The horizontal offset and vertical offset options allow the user to offset all
printing from the left and top edges of the paper, respectively. These
options can be used to help place text onto preprinted forms.
The horizontal offset option specifies a left margin that will be added to
any System-requested left margin in non-COR jobs. The vertical offset
option specifies a top margin that will be added to any System-requested
top margin in non-COR jobs.
The COR horizontal offset and COR vertical offset options specify the
offsets only when the page orientation is COR (Computer Output
Reduction). The default value for these options is .50 inches, which is the
same offset as the IBM 3812 printer.
To program these options:
!AGILE!4A=01; No horizontal offset (default)
!AGILE!4A=02; .05 inch horizontal offset
!AGILE!4A=03; .10 inch horizontal offset
!AGILE!4A=04; .15 inch horizontal offset
!AGILE!4A=05; .20 inch horizontal offset
!AGILE!4A=06; .25 inch horizontal offset
!AGILE!4A=07; .30 inch horizontal offset
!AGILE!4A=08; .35 inch horizontal offset
!AGILE!4A=09; .40 inch horizontal offset
!AGILE!4A=0A; .45 inch horizontal offset
!AGILE!4A=0B; .50 inch horizontal offset
!AGILE!4A=0C; .55 inch horizontal offset
!AGILE!4A=0D; .60 inch horizontal offset
!AGILE!4A=0E; .65 inch horizontal offset
!AGILE!4A=0F; .70 inch horizontal offset
!AGILE!4A=10; .75 inch horizontal offset
!AGILE!4A=11; .80 inch horizontal offset
!AGILE!4A=12; .85 inch horizontal offset
!AGILE!4A=13; .90 inch horizontal offset
!AGILE!4A=14; .95 inch horizontal offset
!AGILE!4A=15; 1.0 inch horizontal offset
