AGILE 5250 ALLY User’s Guide and Reference Page 2-2
A configuration consists of several parts:
• An output port configuration/printer driver, including PFS/GFID
definitions (P%), translation table selections (Group 60) for all
input options, font information (PP & PL) and all printer
configuration options (Groups 40-50)
• Definitions for each character in all sixteen translation tables (#)
• Twinax configuration options (Group 00)
• Alternate host configuration options (Group 30)
Flash
EEPROM
Memory
Output Port Configurations (Printer Drivers)
Master Configuration
Mode B — Save
Power-Up Restore
Printer
Configuration
Options
Printer
PFSs &
GFIDs
Twinax
Configuration
Options
Alt Host
Configuration
Options
Translate Table Definitions
Xerox 3700
ASCII
Xerox 3700
EBCDIC
Generic
H-P
LaserJet 4
As illustrated above, the key step in the configuration of the 5250 ALLY is
loading the output port configuration appropriate for the attached printer.
Because the printer configuration defines and/or overwrites several
configuration options and PFS/GFID definitions, the user should load the
appropriate output port configuration before changing any of these
parameters.
The user also should be aware that after loading an output port
configuration, or after making any configuration change, the configuration
must be saved to the 5250 ALLY’s flash memory, or the changes will be
only temporary.
