Page 5-3 CHAPTER 5 — MAINTENANCE & TROUBLESHOOTING
Twinax Error Log
The 5250 ALLY makes a log of any twinax hardware errors it encounters
on the physical twinax line. Most errors encountered are parity errors
caused by faulty cabling or termination. This feature is useful for
diagnosing the cause of twinax errors. The twinax error log can be printed
using Mode 9-8.
SCS Dump and Hex Dump Samples
In order to illustrate the difference between the SCS Dump and the Hex
Dump modes, the following SCSGEN file was sent to the 5250 ALLY
three different times, once with the unit in Hex Dump mode, once in SCS
Dump mode, and finally in IBM emulation mode:
SCSGEN File
/****************************************************************************
Example test program
****************************************************************************/
program
ovrstk = 0x70; // Set EBCDIC overstrike character (“-”)
avpp 30; // goto line 30
ahpp 30; // column 30
text “Sample test program”;
avpp 32;
ahpp 30;
bus 1; // underscore all
text “This line is underscored”;
eus;
avpp 34;
ahpp 30;
bes; // start emphasis
text “This line is emphasized”;
ees;
avpp 36;
ahpp 30;
bos ovrstk, 1; // overstrike all
text “This line is struck out”;
ff // kick out that page
end
Hex Dump Mode
000000: 34 C4 1E 34 C0 1E E2 81 94 97 93 85 40 A3 85 A2 * D { Sample tes*
000010: A3 40 97 99 96 87 99 81 94 34 C4 20 34 C0 1E 2B *t program D { *
000020: D4 04 0A 01 01 E3 88 89 A2 40 93 89 95 85 40 89 *M. This line i*
000030: A2 40 A4 95 84 85 99 A2 83 96 99 85 84 2B D4 02 *s underscored M *
000040: 0E 34 C4 22 34 C0 1E 2B D1 03 8A 00 E3 88 89 A2 * D { J - This*
000050: 40 93 89 95 85 40 89 A2 40 85 94 97 88 81 A2 89 * line is emphasi*
000060: A9 85 84 2B D1 03 8E 00 34 C4 24 34 C0 1E 2B D4 *zed J - D { M*
000070: 08 72 70 01 00 00 00 00 E3 88 89 A2 40 93 89 95 *.-- This lin*
000080: 85 40 89 A2 40 A2 A3 99 A4 83 92 40 96 A4 A3 0C *e is struck out.*
