146
Changing Your Workstation’s Hardware Configuration
Installing Second Level Cache Boards
Installing Second Level Cache Boards
Before installing second level cache boards, perform the procedure in
Removing the Main Tray Assembly on page 111.
Follow these steps to install second level cache boards into your worksta-
tion.
1 Locate the cache board connectors on the CPU board, as shown in Figure 50.
Figure 50 Cache Boards Location
Cache Board Connectors
