ARENA / RANGER USER GUIDE
EN2Z-0906GE51 R0708 44
TIGER / PANTHER
SERVAL SERVAL SERVAL
LON Bus
Monitoring (Home) Site
Remote Site
Supervisor ARENA
LAN / Modem / VPN
LON Bus
TIGER / PANTHER
SERVAL
Remote ARENA
Fig. 12. “Remote Through ARENA” Site Type
3. Click
the Add button.
Depending on the selected site type, individual dialog pages display for setting
up the site.
When creating a local site, continue with “Create Local Site” section.
When creating a remote site through iLON 10, continue with “Create Remote
Site through iLON 10” section.
When creating a remote site through ARENA, continue with “Create Remote
Site through ARENA” section.
Creating Local Site
1. If not already done, select ´Local` in New site of type on the Sites Overview
pane, and then click the Add button.
2. Under
General , do the following:
a. In Site Name, enter a name for the site.
