Ch 3: Installing Optional Devices
92
Hitachi PC VisionBase 8450H/R Server
5.
Fix the slot bracket with two mounting screws. Mounting screws must be installed in expansion slot (PCI) 1 and
expansion slot (ISA) 1.
SVP board (Optional)
Connect the IMB interface cable (attached to the SVP board) with the board in advance.
4
5
IMB interface cable
