Ch 3: Installing Optional Devices
64 Hitachi PC VisionBase 8450H/R Server
1. Open the storage bay door. See “Opening the Storage Bay Door” on page 41.
2. Take out the hard disk canister from the extended storage bay onto which you want to install the internal hard
disk. When taking out the canister, pull the lever to the front, unlock, and then extract the canister.
The hard disk canister has a label corresponding to the extended storage bay. The following table shows the
correspondence between extended storage bays and labels:
Extended storage bay Label
1 A1
2 A2
3 A3
4 A4
5 A5
6 A6
Lever
Hard disk canister
Label
