Ch 3: Installing Optional Devices
Hitachi PC VisionBase 8450H/R Server 71
2. Remove the FDD cable and FDD power cable from the back of the floppy disk (standard).
3. Remove two mounting screws from the front of the system equipment, then extract the device bracket.
4. Remove two mounting screws from the extended storage bay to be used, then remove the bay cover.
NOTE: Store the removed bay cover properly.
5. Fix device fittings onto the internal DAT with four mounting screws (attached to each internal DAT).
FDD cable
FDD power cable
Device bracket
Bay cover
Fix device fitting
Internal DAT
