Ch 1: Hitachi PC VisionBase 8450H/R Server System Chassis Description
2
Hitachi PC VisionBase 8450H/R Server
Chassis Front View
1.
Operator Panel
2.
Extended storage bays 7–9
3.
3.5-inch floppy disk drive
4.
Front door
5.
Front door lock
6.
Storage bay door
7.
Extended storage bays 1–6
8.
Caster
1
2
3
4
5
6
7
8
1
2
3
6
7
5
VB 8450H
VB 8450R
