Ch 3: Installing Optional Devices
Hitachi PC VisionBase 8450H/R Server
83
3.
Holding the processor with its fin facing upward, and keeping the levers open, insert the processor into the slot
until it stops, then close the levers simultaneously.
NOTE: When you install a terminator for processor, you also need to install levers. See “Installing a Lever onto
the Terminator for Processor” on page 85 for details.
4.
Close the cover.
NOTE: If the claw of the cover cannot be inserted properly, the processor is probably inserted halfway.
Check whether the levers are closed properly.
