Ch 3: Installing Optional Devices
68 Hitachi PC VisionBase 8450H/R Server
2. Remove the FDD cable and FDD power cable from the back of the floppy disk (standard).
3. Remove two mounting screws from the front of the system equipment, then extract the device bracket.
4. Remove two mounting screws from the extended storage bay to be used, then remove the bay cover.
NOTE: Store the removed bay cover properly.
5. Fix the internal CD-ROM onto the device bracket with four mounting screws (attached to each internal
CD-ROM).
FDD cable
FDD power cable
Device bracket
Bay cover
