Page 78
3-22
Replacing Ink System Components
tubes through the guide behind the carriage top cover for
printheads 1, 2, and 3.
Caution
Ensure that the ink tubes will not be pinched or sev-
ered when the top cover is closed.
11. Connect the new ink tube to the ink reservoir.
Ink tray
Tube guides along rear of printer
Tube guides inside the tube chain
Fig. 3-12. Location of tube guides
Fig. 3-13. Connecting the ink tube to the reservoir
