Diagnostics B-7
W-PC-3 - Head Height Changed -
Recalibrate Change in head height has invali-
dated calibration. Run AutoSet (page 2-7).
W-PC-4 - AutoJet - Jets Not Mapped
Out Not all missing jets could be
replaced. Prime/clean printheads (page 5-3),
or increase number of passes (page
3-7).
(PD) Primer Door
A-PD-1 - Door Opened, Prime Not
Selected The primer door is open. Close the primer door.
(PG) Purge
W-PG-1 - Pens Require Purge The printheads should be purged. Purge all printheads (page 5-11).
(SC) System Calibrations
W-SC-1 - Media Adv. Run Out Not
Calibrated Calibration was reset or not per-
formed. Calibrate media advance (page 4-4).
W-SC-2 - White Point Not Calibrated Calibration was reset or not per-
formed.
Calibrate white point (page 2-17).
W-SC-3 - Media Thickness Sensor
Not Calibrated Calibration was reset or not per-
formed. Calibrate media sensor (page 2-17).
W-SC-4 - Head Height Not Cali-
brated Calibration was reset or not per-
formed. Calibrate head height (page 2-17).
W-SC-5 - Printer Length Not Known Calibration was reset or not per-
formed. Calibrate printer length by restarting
printer.
(SM) System
A-SM-1 - Printer Not Imprinted Defective electronics assembly. Call service provider for replacement
electronics.
A-SM-2 - Release S/W Found Debug
S/W Defective software. Call service provider for updated
software.
(SS) Service Station
W-SS-1 Service Station Tray Not
Present The service station is not installed, or
it is installed too far to the right. Install service station properly, or
defeat service station sensor (page
1-13).
(TC) Top Cover
A-TC-1 - Cover Open The top cover is open. Close the top cover.
(TU) Take Up
A-TU-1 - Takeup Full The media takeup spool is full. Unload the takeup spool and reload
media (page 3-24).
Table B-1. Actions and Warnings
