Panasonic TH-55VF2HW 54.6" Full HD Video Wall Display - Manual (Page 88)

English
88
Error response
Error message
Last
terminal
symbol
“ERR1” : Undefined control
command
(CR)
0x0d
“ERR2” : Out of parameter
range
“ERR3” : Busy status or
reception invalid
period
“ERR4” : Timeout or reception
invalid period
“ERR5” : Wrong data length
4 bytes 1 byte
Note
● With some of the commands, a part of character
string of the transmitted data may not be included in
the received data.
● Consult your local Panasonic dealer for detail
instructions on command usage.
For more details, visit the following web site.
https://panasonic.net/cns/prodisplays/
PJLink protocol
The unit’s Network function is compatible with PJLink
Class 1. The following operations can be performed from
a computer when PJLink protocol is used.
● Setting the Display
● Querying the Display status
Supported commands
The commands to control the unit with PJLink protocol
are as follows.
Command Control
POWR Power control
0: Standby
1: Power On
POWR? Power status query
0: Standby
1: Power On
INPT Input switch
11: PC IN input (PC)
31: HDMI input (HDMI)
32: DisplayPort input (DisplayPort)
33: DIGITAL LINK input
(DIGITAL LINK)
34: DVI-D IN 1 input (DVI-D1)
35: DVI-D IN 2 input (DVI-D2)
41: USB input (USB)
INPT? Input switch query
11: PC IN input (PC)
31: HDMI input (HDMI)
32: DisplayPort input (DisplayPort)
33: DIGITAL LINK input
(DIGITAL LINK)
34: DVI-D IN 1 input (DVI-D1)
35: DVI-D IN 2 input (DVI-D2)
41: USB input (USB)
AVMT Shutter control
10: Picture On
(picture mute deactivated)
11: Picture Off
(picture on mute)
20: Audio On
(audio mute deactivated)
21: Audio Off
(audio on mute)
30: Shutter mode Off
(picture and audio mute
deactivated)
31: Shutter mode On
(picture and audio on mute)
