Corresponding signal
Resolution (Dot)
Scanning frequency
Dot clock
frequency
(MHz)
Format
*
3
Horizontal
(kHz)
Vertical
(Hz)
SXGA
1 280 x 1 024
63.98
60.02
108.00
R/Y/D/H/DP/DL
79.98
75.02
135.00
R/Y/D/H/DP/DL
91.15
85.02
157.50
R/Y/D/H/DP/DL
1360 x 768
1 360 x 768
47.71
60.02
85.50
D/H/DP/DL
47.70
60.00
84.72
D/H/DP/DL
47.72
59.80
84.75
D/H/DP/DL
1366 x 768
1 366 x 768
39.55
50.00
69.92
D/H/DP/DL
48.39
60.03
86.71
R/Y/D/H/DP/DL
48.00
60.00
72.00
R/Y/D/H/DP/DL
39.56
49.89
69.00
R/Y/D/H/DP/DL
47.71
59.79
85.50
R/Y/D/H/DP/DL
SXGA+
1 400 x 1 050
65.22
60.00
122.61
D/H/DP/DL
82.20
75.00
155.85
R/Y/D/H/DP/DL
WXGA+
1 440 x 900
55.47
59.90
88.75
R/Y/D/H/DP/DL
55.92
60.00
106.47
R/Y/D/H/DP/DL
1600 x 900
1 600 x 900
46.30
50.00
97.05
D/H/DP/DL
60.00
60.00
108.00
D/H/DP/DL
55.99
59.95
118.25
D/H/DP/DL
55.92
60.00
119.00
D/H/DP/DL
WSXGA+
1 680 x 1 050
65.29
59.95
146.25
R/Y/D/H/DP/DL
UXGA
1 600 x 1 200
*
4
75.00
60.00
162.00
R/Y/D/H/DP/DL
1920 x 1080
1 920 x 1 080
*
5
66.59
59.93
138.50
R/Y/D/H/DP/DL
1 920 x 1 080
67.50
60.00
148.50
R/Y/D/H/DP/DL
WUXGA
1 920 x 1 200
*
4
*
6
74.04
59.95
154.00
R/Y/D/H/DP/DL
*
1: When 1 125(1 035)/60i signal is input, it is displayed as 1 125(1 080)/60i signal.
*
2: Pixel-Repetition signal (dot clock frequency 27.0 MHz) only
*
3: Signals to represent formats are as follows.
R : D-sub RGB (PC IN)
Y : YC
B
C
R
/YP
B
P
R
(PC IN)
D : DVI-D (DVI-D IN 1, DVI-D IN 2)
H : HDMI (HDMI)
DP : DisplayPort (DisplayPort)
DL : DIGITAL LINK (DIGITAL LINK)
The analogue input supports onG and onY.
*
4: Displayed with image elements thinned out in the image processing circuit.
*
5: Based on VESA CVT-RB (Reduced Blanking) standard
*
6: Not supported when [DIGITAL LINK mode] is set to [Long reach].
Note
●
An auto detected signal format may be differently displayed from the actual input signal.
●
[ i ] shown after the number of dots of resolution means the interlace signal.
●
When 1 125(1 080)/30PsF signal and 1 125(1 080)/25PsF signal are input, they are processed as 1 125(1 080)/60i
signal and 1 125(1 080)/50i signal, and then displayed.
